No. Part No. Qty. Description
1 60210607 1 NUT
2 60506005 1 Lock Washer
3 21001030 1 STOP
4 21001020 1 TIE ROD
5 60220603 1 NUT, LOCK
6 60306007 1 Washer
7 60220603 1 NUT, LOCK
8 46110100 1 FRONT FRAME
9 21001010 1 TANK PIN
10 60220801 1 Lock Nut
11 60308004 1 WASHER
12 47210070 1 COMPRESSION SPRING 12x1,6x15
13 20102210 1 WASHER
14 60110812 1 SCREW
15 60100802 1 SCREW,M8X20
16 60140304 1 SCREW M3x14
17 63409002 1 MICROSWITCH
18 60303004 1 WASHER
19 60100613 1 SCREW
20 60306010 1 Washer M6x24x2
21 60220603 1 NUT, LOCK
22 48010010 1 BATTERY COMPARTMENT
23 60100601 1 SCREW M6x16
24 60101010 1 SCREW
25 60210608 1 NUT,M6
26 60506002 1 WASHER, LOCK
27 60110612 1 SCREW, M6x20
28 21007010 1 WHEEL PIN
29 46514010 2 RUBBER WHEEL
30 60311001 1 WASHER
31 60221002 1 Lock Nut M10
32 62040002 1 NUT COVER BLACK
33 62405010 1 ADHESIVE PLASTIC CAP
