No. Part No. Qty. Description
1 48310010 1 Rear blade
2 48410060 1 Rear Squeegee Rubber
3 61706004 1 Wing Nut INOX
4 21005030 1 Squeegee Coupling
5 48210010 1 Squeegee Body
6 60140509 1 Screw M5 X12 INOX
7 60110611 2 Screw M6x20 INOX
8 60306005 2 Washer M6x12x1.6 INOX
9 47110010 2 Bushing
10 46550010 4 Wheel
11 21004020 1 Right Wheel Support
12 60220602 2 Lock Nut INOX
13 60210601 1 Nut INOX
14 60170606 2 Screw M6 X 40 INOX
15 48210020 1 Inner Rubber Holder Support
16 48410010 1 Front Squeegee Rubber
17 60170605 2 SCREW M6 x 25
18 21004030 1 Left Wheel Support
19 60110616 2 Screw M6x25 INOX
20 21004010 1 Rear Coupler
21 62200006 1 Closing INOX
22 V8210030 1 Squeegee Assembly
23 60140201 1 Screw M2.5x6 INOX
24 60210601 1 Nut INOX
