No. Part No. Qty. Description
1 V1005001 1 Squeegee Arm Assembly
2 60140513 1 Screw M5x30
3 60210503 1 Nut
4 60221002 1 Lock Nut M10
5 47110020 1 Brass bushing
6 21005010 1 Arm Joint
7 60110608 1 Screw M6X16
8 60506005 1 Lock Washer
9 60306007 1 Washer
10 60220803 2 Lock Nut INOX
11 60140503 2 Screw M5x12
12 60505003 2 Lock Washer INOX
13 60305003 2 Washer INOX
14 21005100 1 Chain
15 20203050 2 Stud Bolt
16 60140505 1 Screw M5x16
17 60305005 2 Washer
18 60220502 1 Lock Nut INOX
