Page #48 background imageLoading...
Page #48 background image
No. Part No. Qty. Description
1 60190306 1 VITE D.2,9x9,5 AUTOF.TC UNI 6954 DIN7981
2 60304004 1 WASHER
3 21010050 1 PROTECTION
4 62350010 1 COVER SOLUTION TANK
5 47301010 1 TANK, SOLUTION
6 62350009 1 PLUG
7 21010040 2 COUPLER SQUEEGEE HOSE
47610325 SQUEEGEE HOSE W/COUPLERS
8 47610320 1 SQUEEGEE HOSE
47610325 SQUEEGEE HOSE W/COUPLERS
9 21010040 1 COUPLER SQUEEGEE HOSE
47610325 SQUEEGEE HOSE W/COUPLERS
10 47310020 1 RECOVERY TANK
11 60110618 1 SCREW INOX M6x30
12 47210080 1 SPRING, COMPRESSION INOX
13 61820002 2 LEVER, BLOCKING
14 21010030 1 FILTER CAP
15 60120403 1 SCREW INOX
16 47800010 1 CAP, GASKET FILTER
17 47900010 1 FLOAT, FILTER
18 20110060 1 ROD W/ PLATE
19 20110070 1 FLOAT
20 60140615 1 SCREW
21 49320120 1 SUCTION MOTOR
22 48110010 1 SIDE DEADENING SUCTION
23 48110020 1 LOWER DEADENING SUCTION
24 47610310 1 SUCTION HOSE
47610315 SUCTION HOSE COMPLETE
25 21010020 1 BENT FITTING
47610315 SUCTION HOSE COMPLETE
26 47650050 1 DEADENING HOSE
47610315 SUCTION HOSE COMPLETE
27 62370008 1 GASKET FOR PLUG
