10
OPERATION
General Instructions for the TE070-G15-U Extractor
Follow these easy step by step instructions to ensure proper operating performance.
1. If you are not pre-spraying the chemical on the carpet, lift the solition tank cover and fill the
solution tank. Fig. 2, with tap water that is 120
o
-135
o
F (49
o
-57
o
C) and approved carpet cleaning
chemical, following the mixing instructions for the chemical being used, into the solution tank.
2. Attach the extension cord to the socket on the back of unit (Fig. 3).
3. Plug the other end of the extension cord into a grounded 15 amp wall socket circuit.
4. Attach the hose system to the unit and to your carpet wand.
5. Turn the pump switch (#2 Fig. 1) to the “ON” position .
6. Turn the vacuum switch (#1 Fig. 1) to the ON” position to begin cleaning.
7. When recovery tank is full, empty by using drain hose on the front of machine. If a pail is used
to empty the recovery tank, do not use the same pail to fill the solution tank as this can result in
putting dirt and grit into the solution line that can plug filters, orifices, and generally degrade the
solution line system (do not reuse solution).
8. To empty solution tank, detach the wand from the end of the vacuum hose and insert the
vacuum hose into the solution tank. Turn the vacuum switch to the “ON” position and transfer
solution to the recovery tank and dispose of as outlined in #7.
Fig. 3Fig. 2
