5
TECHNICAL DESCRIPTION U/M T120-S53-U
Cleaning width mm/in 508/20
Squeegee width mm/in 770/30
Working capacity sqm/h/sqft/h 2000/21,528
Brush diameter mm/in 508/20
Brush rpm rpm 155
Pressure on the brush kg/lbs 30/66 max
Brush motor W/A 450/18.8
Type of drive automatic
Maximum gradient % 2
Suction motor W/A 450/18.8
Suction vacuum mbar\in water
lift
120/48
Solution tank l/gal 40/11
Recovery tank l/gal 45/12
Machine length mm/in 1195/47
Machine height mm/in 1053/42
Machine width (without squeegee) mm/in 530/21
Weight of the batteries kg/lbs 74/163
Compartment of the batteries mm/in 342x340x295 /13.5x13.4x11.6
Weight of the machine (empty and without
batteries)
kg/lbs 76/168
Acoustic pressure level (in conformity with
IEC 704/1)
dB(A) <70
Class III
Protection level IP X3
Tension V 24
− Do not take off the
protections which require the
use of tools for their removal.
− Do not wash the machine
with direct water, jets or with
high water pressure nor with
corrosive material.
− Every 200 working hours
have a machine check by an
authorized service department.
− Before using the machine,
check that all panels and
coverings are in their position
as indicated in this use and
maintenance catalogue.
− Do not place any metallic
tools onto the batteries. Risk
of short circuit!
− It is compulsory to hand
over exhaust batteries,
classified as dangerous waste,
to an authorized institution
according to the current laws.
GENERAL RULES OF THE
BATTERIES
At any intervention on the
batteries, use suitable acid-
proof gloves and glasses.
− Do not smoke near the
batteries and do not approach
them with free flames.
− Check that a fire-
extinguisher is available on
site.
− Be very careful in case of
leakages or liquid outlets
because corrosive.
