Tornado TS120-S53-U User Manual

7
MACHINE
1. BRUSH BASE GROUP
2. PLUG EXHAUST HOSE RECOVERY TANK
3. RECOVERY TANK
4. INSTRUMENT BOARD
5. LEVERS MOVEMENT
6. SCREW CAP FOR INLET DETERGENT
SOLUTION
7. GUIDE SPRING SQUEEGEE HOSE
8. SQUEEGEE HOSE
9. BATTERIES
10. INLET OPENING SQUEEGEE HOSE
11. SUCTION COVER
12. SOLUTION TANK
13. WHEELS
14. SQUEEGEE ASSEMBLY
15. CASTOR WHEELS
INSTRUMENT BOARD AND CONTROLS
1. IGNITION SWITCH
2. BATTERIES CHARGE LEVEL SIGNAL
3. BRUSH MOTOR SWITCH
4. SUCTION MOTOR SWITCH
5. SOLENOID VALVE SWITCH
6. LEVERS DRIVE CONTROL
7. LEVER SOLUTION VALVE
8. LEVER SQUEEGEE LIFTING
9. PEDAL BRUSH BASE GROUP LIFTING

Tornado TS120-S53-U Specifications

General

Brand	Tornado
Model	TS120-S53-U
Category	Scrubber
Language	English
