Toro 03691 User Manual

2
AdjustingtheControl-Arm
Position
NoPartsRequired
Procedure
Thecontrol-armpositioncanbeadjustedforyour
comfort.
1.Loosenthe2boltssecuringthecontrolarmto
theretainingbracket(Figure3).
g004152
Figure3
1.Controlarm3.Bolts(2)
2.Retainingbrackets
2.Rotatethecontrolarmtothedesiredposition
andtightenthe2bolts.
3
InstallingtheCuttingUnits
Partsneededforthisprocedure:
1
Rightfronthoseguide
1
Leftfronthoseguide
PreparingtheMachine
1.Removethereelmotorsfromtheshipping
brackets.
2.Removeanddiscardtheshippingbrackets.
3.Ateachcuttingunitliftarm,removethelynchpin
thatsecuresthecaptotheliftarmpivotyoke,
andremovethecap(Figure4).
g003975
Figure4
1.Lynchpin
2.Cap
PreparingtheCuttingUnits
1.Removethecuttingunitsfromthecartons.
2.Assembleandadjustasdescribedinthecutting
unitOperator'sManual.
3.Makesurethatthecounterweight(Figure5)is
installedattheproperendofthecuttingunitas
describedinthecuttingunitOperator'sManual.
11

Toro 03691 Specifications

General

Brand	Toro
Model	03691
Category	Lawn Mower
Language	English
