Checking the Hydraulic-Fluid Level (continued)
G425419
3. Remove the hydraulic-tank cap from the
tank.
4. Remove the dipstick
from the filler neck and
wipe it with a clean rag.
5. Insert the dipstick into the filler neck; then
remove it and check the fluid level.
The correct hydraulic-fluid level is between the
full mark
and the add mark on the
dipstick.
6. If the level is low, add the specified hydraulic
fluid to raise the fluid level to the full mark.
7. Install the dipstick and hydraulic-tank cap to
the tank.
Replacing the Hydraulic Filters
Use the following Toro hydraulic filters:
Name Toro Part No. Location
Return filter 94-2621 Below the right frame channel.
Charge filter 75-1310 Under the seat plate.
IMPORTANT
Using another type of filter may void the warranty on some components.
Changing the Charge Filter
1. Prepare the machine for maintenance.
2. Tilt the seat.
