Mow-Speed Limiter
G467875
Rotate limiter forward—allows the cutting units to
engage and limits the maximum ground speed
during mowing.
Rotate limiter backward—to achieve maximum
ground speed between job sites.
Spacers—change the position to adjust mowing
ground speed.
Forward speed-limiter screw—adjust to limit the
amount the traction pedal can be pressed in the
forward direction.
Reverse speed-limiter screw—adjust to limit the
amount the traction pedal can be pressed in the
reverse direction.
IMPORTANT
The speed-limiter screws must stop the traction
pedal before the pump reaches full stroke;
otherwise, damage to the pump may occur.
Power Point
G467886
The power point is a 12 V
power supply for electronic
devices.
Bag Holder
G467887
Use the bag holder for
storage.
Product Overview: Controls Page 4–5 3466-702 A
