Preparing the Cutting Units
G409089
1. Remove the cutting units from the cartons.
2. Assemble and adjust as described in the
cutting unit Operator's Manual.
3. Make sure that the counterweight
is
installed at the proper end of the cutting unit as
described in the cutting unit Operator's
Manual.
Positioning the Turf Compensating Spring and Installing
the Hose Guide
Cutting Unit 4
G410291
Cutting unit 1
Cutting unit 2
Cutting unit 3
Cutting unit 4
Cutting unit 5
Reel motor
Weight
Setup: Installing the Cutting Units Page 3–2 3466-702 A
