Toro 04540 User Manual

securethemwiththeboltsandnuts(Figure7).
Slidetherubberbootoverthepositiveterminal
topreventapossibleshortfromoccurring.
WARNING
Incorrectbatterycableroutingcoulddamage
thetractorandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
g005098
Figure7
1.Negative(-)
2.Positive(+)
5
InstallingtheOilCooler
Optional
Partsneededforthisprocedure:
–
OilCoolerKit—Greensmaster3300SeriesTraction
Unit(PartNo.119-1691[purchasedseparately])
Procedure
Ifyouareoperatingthemachineinhotclimates,
wheretheambienttemperatureisabove29°C(85°F),
orusingitforheavy-dutyuse(mowingotherthan
greens,suchasfairwaysorverticutting),installthe
optionalhydraulicoilcoolerkit(PartNo.119-1691).
6
InstallingtheGrass-Basket
Hooks
Partsneededforthisprocedure:
6
Grass-baskethook
12Flangebolts
Procedure
Installthe6grass-baskethooksontotheendsofthe
suspension-armbarsusingthe12angebolts(Figure
8).
g015492
Figure8
1.Flangebolt
3.Suspension-armbar
2.Grass-baskethook
14
