FuelSystem
Maintenance
DrainingWaterfromthe
FuelFilter
ServiceInterval:Beforeeachuseordaily
1.Parkthemachineonalevelsurfaceandshut
offtheengine.
2.Placeadrainpanunderthefuellter.
3.Openthedrainplugonthefuellter
approximatelyoneturnanddrainany
accumulatedwater(Figure35).
g014720
Figure35
1.Fuellter
2.Drainplug
4.Tightentheplugafterdraining.
Note:Becausetheaccumulatedwaterwillbe
mixedwithdieselfuel,drainthefuellterintoa
suitablecontaineranddisposeofitproperly.
ReplacingtheFuel
Filter/WaterSeparator
ServiceInterval:Every800hours
1.Closethefuel-shutoffvalve(Figure36)below
thefueltank.
g014626
Figure36
1.Fuel-shutoffvalve
2.Cleantheareawheretheltercanistermounts
(Figure37).
3.Placeadrainpanunderthefuellter.
4.Openthelterdrainplug(Figure37).
g014720
Figure37
1.Fuellter/waterseparator
canister
2.Filter-drainplug
5.Unscrewtheltercanisteranddisposeofit
accordingtolocalregulations.
