Toro 04613 - Backlapping the Reel

g014642
1
2
Figure16
1.Springtensionnut2.Spring
7.Adjustthebedknifetothereel;refertoAdjustingthe
BedknifetotheReel.
BacklappingtheReel
DANGER
Contactwiththereelorothermovingpartscan
resultinpersonalinjury.
Keepngers,hands,andclothingawayfromthe
reelsorothermovingparts.
•Stayawayfromthereelwhilebacklapping.
•Neveruseashorthandledpaintbrushfor
backlapping.PartNo.29-9100Handleassembly
completeorindividualpartsareavailablefrom
yourlocalAuthorizedToroDistributor.
1.Positionthemachineonaclean,levelsurface,lower
thecuttingunits,stoptheengine,engagetheparking
brake,andremovetheignitionkey.
2.Removethereelmotorsfromthecuttingunitsand
disconnectandremovethecuttingunitsfromthelift
arms.
3.Connectthebacklappingmachinetothecuttingunit
byinsertingapieceof3/8inchsquarestockintothe
splinedcouplingintheendofthecuttingunit.
Note:Additionalinstructionsandprocedureson
BacklappingareavailableintheToroSharpeningReeland
RotaryMowersManual,FormNumber80-300PT.
Note:Forabettercuttingedge,runaleacrossthe
frontfaceofthebedknifeandreelwhenthelapping
operationiscompleted.Thiswillremoveanyburrsor
roughedgesthatmayhavebuiltuponthecuttingedge.
