6. Move the control knobs to the middle position
as shown in Figure 6 .
g430155
Figure 6
1. Move the knobs to the middle position.
7. Ensure that the heater switch is in the middle
position and connect one end of the control
cable to the back of the heater switch ( Figure 7 ).
g430382
Figure 7
8. Ensure that the water valve is in the middle
position and connect it onto the other end of the
control cable ( Figure 8 ).
9. Ensure that the heater switch can sweep from
low heat to high heat and that the water valve
fully opens and closes. Adjust the cable if
necessary .
g460374
Figure 8
5
