Toro 08743 - Installing the Front Weights; Applying the Production Year Decal and CE Decal

3.Securethesmallblackwireandthenegative
cable(black)tothenegative(-)terminalofthe
batterywithabolt(1/4x5/8inch)andlocknut
(1/4inch)(Figure6).
4.Coattheterminalsandmountingfastenerswith
petroleumjellytopreventcorrosion.
5.Slidetherubberbootoverthepositive(+)
terminaltopreventapossibleshortfrom
occurring.
6.Installthetopbatteryhold-downtotheside
batteryhold-downsandsecureitwiththe
washersandwingnuts.
4
InstallingtheFrontWeights
Partsneededforthisprocedure:
–
Frontweightkit(s)asneeded
Procedure
Thismachinehasbeendesignedinaccordancewith
ANSIB71.4-2017.However,whenattachmentsare
installedonthemachineadditionalweightmaybe
requiredtocomplytothestandards.
1.Usethechartbelowtodeterminethe
combinationsofadditionalweightrequired.
OrderpartsfromyourauthorizedTorodistributor.
AttachmentWeight
Required
WeightKit
KitQuantity
SpikerKit
Rahn
Groomer
23kg(50lb)
PartNo.100-64421
Note:ForModel08745machines,donotinstall
theweightkitifyourmachineisequippedwith
thefrontliftframekit.
2.Installtheweightkit;refertotheInstallation
Instructionsfortheweightkit.
5
ApplyingtheProduction
YearDecalandCEDecal
CEOnly
Partsneededforthisprocedure:
1Productionyeardecal
1
CEdecal
Procedure
ApplytheproductionyeardecalandtheCEdecalto
themachineintheareashown(Figure7).
g339442
Figure7
1.Applytheproductionyeardecalhere.
2.ApplytheCEdecalhere.
10
