Toro 08743 - Installing the Steering Wheel; Installing the Seat

1
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1
Steeringwheel
1Foamcollar
1Washer
1Locknut
1
Steering-wheelcover
Procedure
1.Movethefrontwheelsothatitpointsstraight
ahead.
2.Slidethefoamcollar,smallendrst,ontothe
steeringshaft(Figure3).
g025723
Figure3
1.Foamcollar4.Nut
2.Steeringwheel5.Steering-wheelcover
3.Washer
3.Slidethesteeringwheelontothesteeringshaft
(Figure3).
4.Securethesteeringwheeltothesteeringshaft
withawasherandalocknut(Figure3).
5.Torquethelocknutto27to35N∙m(20to26
ft-lb).
6.Pressthesteering-wheelcoverintopositionon
thesteeringwheel(Figure3).
2
InstallingtheSeat
Partsneededforthisprocedure:
1
Seat
Procedure
1.Removeanddiscardthelagboltssecuringthe
seattothecrate.
2.Removethenutsfromtheshippingbracketand
discardthebracket.Savethenuts.
3.Securetheseattotheseatbasewiththe4
previouslyremovednuts;refertoFigure4.
g334906
Figure4
1.Seat
4.Flangenut
2.Seatswitch
5.Machinewireharness
3.Seatbolts
4.Locatethemachinewireharnessandconnect
ittotheseatswitch(Figure4).
5.Securethewireharnesstotheseatbasewith
acabletie.
8
