Figure 7
1. Starter rope
2. Rope guide
2. Filling the Engine with Oil
Y our mo w er does not come with oil in the engine .
1. R emo v e the dipstic k ( Figure 8 ).
Figure 8
2. Slo wl y pour oil into the oil fill tube until the oil lev el
reac hes the Full line on the dipstic k ( Figure 8 ). Do not
o v erfill. (Max. fill: 20 oz. (0.59 l), type: SAE 30W
deterg ent oil with an API ser vice classification of SF ,
SG , SH, SJ , SL, or higher .)
3. Install the dipstic k securely .
Important: Change the engine oil after the fir st 5
operating hour s ; change it y ear l y ther eafter . R efer
to Changing the Engine Oil.
Product Overview
Figure 9
1. Recoil start handle
6. Primer
2. Handle knob (4)
7. Spark plug
3. Fuel tank cap
8. Cutting height lever (4)
4. Side discharge 9. Oil ll/Dipstick
5. Air lter 10. Blade control bar
Figure 10
1. Side discharge chute
2. Rear discharge plug (installed)
5
