Toro 20093 - Bagging the Clippings

Figure24
1.Dischargedeector
2.Reardischargeplug
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassand
leafclippingsfromthelawn.
Aworngrassbagcouldallowdebristobe
thrownandresultinseriouspersonalinjuryor
deathtotheoperatororbystanders.
Checkthegrassbagfrequently.Ifitis
damaged,installanewTororeplacementbag.
Ifthesidedischargechuteisonthemower,removeit
andlockthesidedischargedoor(refertoRemovingthe
SideDischargeChute)beforebaggingtheclippings.
Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
InstallingtheGrassBag
1.Routethestarterropearoundthelowerropeguide
(Figure25).
Figure25
1.Lowerropeguide
Note:Thelowerropeguidereleasesthestarterrope
whenyoupulltherecoilstarthandle.
2.Raiseandholdupthedischargedeector(Figure26).
Figure26
1.Dischargedeector
2.Reardischargeplug
3.Pulloutthereardischargeplug(Figure26).
4.Hangtheupperfrontedgeofthebagonthenotches
(Figure27).
Figure27
1.Dischargedeector2.Grassbag
5.Lowerthedischargedeector.
