5.Torquethehandleboltsto120to160in-lb(14to
17Nm).
6.Adjustthecuttingheight.RefertoAdjustingthe
CuttingHeight.
3.InstallingtheStarterRope
Procedure
Pullthestarterropethroughtheropeguideonthe
handle(Figure6).
Figure6
1.Starterrope
2.Ropeguide
Note:Tomaketheropeeasiertoinstall,squeezethe
controlbaronthehandle.
4.FillingtheEnginewithOil
Procedure
Yourmowerdoesnotcomewithoilintheengine.
1.Removethedipstick(Figure7).
Figure7
2.Slowlypouroilintotheoillltubeuntiltheoillevel
reachestheFulllineonthedipstick(Figure7).Do
notoverll.(Max.ll:20oz.(0.59l),type:SAE
30WdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.)
3.Installthedipsticksecurely.
Important:
Change the engine oil after the r st
5 operating hour s
;changeityearlythereafter.
RefertoChangingtheEngineOil.
ProductOverview
Figure8
1.Upperhandle
7.Cuttingheightlever(4)
2.Controlbarlock8.Oilll/Dipstick
3.Fueltankcap9.Recoilstarthandle
4.Sidedischarge
10.Ignitionswitch
5.Airlter
11.Bladecontrolbar
6.Sparkplug
Figure9
1.Grassbag
3.Reardischargeplug
(installed)
2.Sidedischargechute
6
