Toro 20382 - Bagging the Clippings

BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
Note:Ensurethebagisseatedinthecorrectposition.
WARNING
Aworngrassbagcouldallowdebristobethrown
andresultinseriouspersonalinjuryordeathtothe
operatororbystanders.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
Iftheside-dischargechuteisonthemachine,removeit
andlocktheside-dischargedoor;refertoRemovingthe
Side-dischargeChute(page13)beforebaggingtheclippings.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheGrassBag
1.Routethestarterropearoundthelowerropeguide
(Figure19).
G017483
Figure19
1.Lowerropeguide
Note:Thelowerropeguidereleasesthestarterrope
whenyoupulltherecoil-starthandle.
2.Raiseandholdupthedischargedeector(Figure20).
G017464
Figure20
1.Dischargedeector
2.Rear-dischargeplug
3.Pullouttherear-dischargeplug(Figure20).
4.Hangtheupperfrontedgeofthebagonthenotches
(Figure21).
G017484
Figure21
1.Dischargedeector2.Grassbag
Note:Ensurethatthegrassbagissecurelyinstalled
ontothemachine.
5.Lowerthedischargedeector.
11
