4.Iftheairlterisdamagedoriswetwithoilorfuel,
replaceit.
5.Iftheairlterisdirty,tapitonahardsurfaceseveral
timesorblowcompressedairlessthan30psi(207kPa)
throughthesideofthelterthatfacestheengine.
Donotbrushthedirtoffthelter;brushingforces
dirtintothebers.
6.Removedirtfromtheaircleanerbodyandcoverusing
amoistrag.Donotwipedirtintotheairduct.
7.Installthelterintotheaircleaner.
8.Closethecover.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
Yearly
Runtheengineafewminutesbeforechangingtheoiltowarm
it.Warmoilowsbetterandcarriesmorecontaminants.
1.Performthepre-maintenanceprocedures;referto
PreparingforMaintenance(page15).
2.Removethedipstick.
3.Tipthemachineontoitsside,withthedipstickdown,
todraintheusedoiloutthroughtheoil-lltube(Figure
33
).
G017485
Figure33
4.Afterdrainingtheusedoil,returnthemachinetothe
normaloperatingposition.
5.Removethedipstickandpourabout3/4ofthe
crankcasecapacityofoilintotheoil-lltube.
Note:Max.ll:0.58quartor18.6oz.(0.55l),type:
SAE30orSAE10W-30detergentoilwithanAPI
serviceclassicationofSF ,SG,SH,SJ,SL,orhigher.
6.Wipeoffthedipstickendwithacleancloth.
7.Insertthedipstickintotheoil-lltube.
8.Removethedipstickandreadtheoillevelonthe
dipstick(Figure34).
G017491
Figure34
•Iftheoillevelistoolow ,addasmallamountof
oilslowlytotheoil-lltube,andthenrepeatsteps
6through8untiltheoillevelonthedipstickis
correct.
•Iftheoillevelistoohigh,draintheexcessoiluntil
theoillevelonthedipstickiscorrect.
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
9.Installthedipsticksecurely.
10.Recycletheusedoilproperly.
LubricatingtheWheelGears
ServiceInterval:Every25hours
1.Wipethegreasettingsjustinsidetherearwheelswith
acleanrag(Figure35).
16
