Toro 20382 - 1 Assembling and Unfolding the Handle; Setup

Setup
1
AssemblingandUnfoldingthe
Handle
NoPartsRequired
Procedure
WARNING
Assemblingandunfoldingthehandleimproperly
candamagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenassemblingand
unfoldingthehandle.
•Ensurethatthecablesareroutedtotheoutside
ofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemachinehousingtoitshighest
cuttingheightsettingbymovingthe2rearcutting
heightleversallthewayforward.RefertoAdjusting
theCuttingHeight(page9).
2.Attachthehandleendstothemachinehousingwith
2washersand2handlebolts(Figure3),butdonot
tightenthehandlebolts.
G017457
Figure3
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestothe outside ofthe
handle(Figure3).
3.Rotatethehandlerearward(Figure4).
G017479
Figure4
4.Lockthehandleatyourdesiredheight.Referto
AdjustingtheHandleHeight(page9).
5.Torquethehandleboltsto120to160in-lb(14to17
N-m).
6.Adjustthecuttingheight.RefertoAdjustingthe
CuttingHeight(page9).
5
