Toro 22321 - Closing the Rear Access Cover; Removing the Side Screens; Installing the Side Screens; Removing the Front Screen

Figure24
1.Handknob
2.Tilttherearaccesscoverdownandremovetoaccess
theinternalcomponents(Figure24).
ClosingtheRearAccess
Cover
1.Movetherearaccesscoverinplaceovertheback
ofthetractionunitmakingsurethetabslineupin
theslots.
2.Pushtheaccesscoverforward,liningupthehand
knobscrewswiththethreadedholesinthemachine.
3.Screwthehandknobstighttosecuretherearaccess
coverinplace.
RemovingtheSideScreens
1.Openthehood.
2.Slidethesidescreens(Figure25)upandoutofthe
slotsinthefrontscreenandframe.
Figure25
1.Sidescreen
InstallingtheSideScreens
Slidethesidescreensintoplaceintheslotsinthefront
screenandframe.
RemovingtheFrontScreen
Iftheenginehasbeenrunningtheheatshield
willbeveryhotandcouldburnyou.
Allowthetractionunitcoolcompletelybefore
touchingtheheatshield.
1.Openthehoodandremovebothsidescreens.
2.Loosentheboltssecuringthefrontweight
(Figure26).
Figure26
1.Frontweight3.Heatshield
2.Bolts
4.Carriagebolts
3.Removethecarriageboltsandnutssecuringtheheat
shield(Figure26).
4.Lifttheheatshieldupandoffofthetractionunit.
5.Removethe4boltssecuringthefrontscreentothe
tractionunitframe(Figure27).
Figure27
1.Frontscreen
2.Bolts(leftsideboltnot
shown)
