Toro 22337CP - Setup

Setup
1
InstallingtheValveLever
Partsneededforthisprocedure:
1
Speedselectorvalvelever
Procedure
1.Removeanddiscardthenutsecuringtheboltand
lockwashertothespeedselectorlever.
2.Securethelevertothespeedselectorvalveusingthe
boltandlockwasherasillustratedin
Figure4.
Figure4
1.Speedselectorvalvelever2.Speedselectorvalve
2
CheckingFluidLevels
NoPartsRequired
Procedure
Beforestartingtheengineforthersttime,checkthe
engineoil,hydraulicuid,andenginecoolantlevels.
RefertoOperationformoreinformation.
3
InstallingtheBattery
Partsneededforthisprocedure:
1
Maintenance-freebattery
Procedure
Thetractionunitisshippedwithoutabattery.Your
dealerwillprovideamaintenancefreebatterywiththe
product.
WARNING
Batteryterminalsormetaltoolscouldshortagainst
metalcomponents,causingsparks.Sparkscan
causethebatterygassestoexplode,resultingin
personalinjury.
•Whenremovingorinstallingthebattery,donot
allowthebatteryterminalstotouchanymetal
partsofthetractionunit.
•Donotallowmetaltoolstoshortbetweenthe
batteryterminalsandmetalpartsofthetraction
unit.
1.Removethefourboltssecuringthebatterycover
andremovethecover(
Figure5).
Figure5
1.Batterycover5.Nut
2.Bolt6.Positivecable
3.Battery7.Negativecable
4.Bars
2.Removethenutsandbarswhichwillsecurethe
battery(Figure5).
3.Chargethebatteryfor10to15minutesat25to
30ampsor30minutesat4to6amps.Donot
overchargethebattery.
12
