8.Inspectthenewlter(s)fordamagebylookinginto
thelterwhileshiningabrightlightontheoutside
ofthelter.Holesinthelterwillappearasbright
spots.Inspecttheelementfortears,anoilylm,or
damagetotherubberseal.Ifthelterisdamaged
donotuseit.
9.Ifyouarereplacingthesafetylter,carefullyslide
thenewlterintothelterbody(
Figure28).
Important:Topreventenginedamage,always
operatetheenginewithbothairltersandcover
installed.
10.Carefullyslidetheprimarylteroverthesafetylter
(
Figure28).Ensurethatitisfullyseatedbypushing
ontheouterrimofthelterwhileinstallingit.
Important:Donotpressonthesoftinsidearea
ofthelter.
11.Installtheaircleanercoverwiththesideindicatedas
UPfacingupandsecurethelatches(
Figure28).
12.Closetherearaccesscover.
ServicingtheEngineOil
Changeoilandlteraftertherst50operatinghours
andthenevery75operatinghoursthereafter.
Note:Changeoilmorefrequentlywhenoperating
conditionsareextremelydustyorsandy.
OilType:Detergentdieselengineoil(APIservice
CH-4,CI-4orhigher)
CrankcaseCapacity:w/lter,0.84gal.(3.2l)
Viscosity:
•Fortemperaturesabove0°F(-18°C),use15W-40
(preferred)or10W-30.
•Fortemperaturesbelow32°F(0°C),use5W-30.
ChangingtheOilandFilter
ServiceInterval:Aftertherst50hours
Every75hours
1.Starttheengineandletitrunforveminutes.This
warmstheoilsoitdrainsbetter.
2.Parkthetractionunitsothatthedrainsideisslightly
lowerthantheoppositesidetoensurethattheoil
drainscompletely.
3.Lowertheloaderarms,chockthewheels,stopthe
engine,andremovethekey.
CAUTION
Componentswillbehotifthetractionunithas
beenrunning.Ifyoutouchhotcomponentsyou
maybeburned.
Allowthetractionunittocoolbeforeperforming
maintenanceortouchingcomponentsunder
thehood.
4.Placeapanundertheoildraintube(Figure29).
Figure29
1.Clamp
2.Oildraintube
3.Plug
5.Loosentheclampandremovetheplug(Figure29).
6.Whentheoilhasdrainedcompletely,replacethe
plugandtightentheclamp.
Note:Disposeoftheusedoilatacertiedrecycling
center.
7.Opentherearaccesscover.
8.Removetheoldlterandwipethelteradapter
(
Figure30)gasketsurface.
Figure30
1.Oillter
3.Adapter
2.Gasket
9.Pournewoilofthepropertypeinthroughthecenter
holeofthelter.Stoppouringwhentheoilreaches
thebottomofthethreads.
10.Allowaminuteortwofortheoiltobeabsorbedby
ltermaterial,thenpourofftheexcessoil.
11.Applyathincoatofnewoiltotherubbergasketon
thereplacementlter(Figure30).
