Lubrication
GreasingtheTractionUnit
ServiceInterval:Beforeeachuseordaily
Greaseallpivotjointsevery8operatinghoursand
immediatelyaftereverywashing.
GreaseType:General-purposegrease.
1.Lowertheloaderarmsandstoptheengine.Remove
thekey.
2.Cleanthegreasettingswitharag.
3.Connectagreaseguntoeachtting(Figure26and
Figure27).
Figure26
Figure27
4.Pumpgreaseintothettingsuntilgreasebeginsto
oozeoutofthebearings(approximately3pumps).
5.Wipeupanyexcessgrease.
EngineMaintenance
ServicingtheAirCleaner
PrimaryFilter:Replaceafterevery200operatinghours
ormoreoftenindustyconditions.
SafetyFilter:Replaceafterevery600operatinghours.
Note:Servicetheaircleanermorefrequentlyif
operatingconditionsareextremelydustyorsandy.
ReplacingtheFilters
ServiceInterval:Every200hours
Every600hours
1.Lowertheloaderarms,stoptheengine,andremove
thekey.
2.Opentherearaccesscover.
3.Releasethelatchesontheaircleanerandpulltheair
cleanercoveroffoftheaircleanerbody(Figure28).
Figure28
1.Latches
4.Primarylter
2.Aircleanercover
5.Safetylter
3.Airlterbody
6.Dustcap
4.Squeezethedustcapsidestoopenitandknockthe
dustout.
5.Cleantheinsideoftheaircleanercoverwith
compressedair.
6.Gentlyslidetheprimarylteroutoftheaircleaner
body(Figure28).Avoidknockingthelterintothe
sideofthebody.
Important:Donotattempttocleantheprimary
lter.
7.Removethesafetylteronlyifyouintendtoreplace
it.
Important:Neverattempttocleanthesafety
lter.Ifthesafetylterisdirty,thentheprimary
lterisdamagedandyoushouldreplaceboth
lters.
