Premaintenance
Procedures
OpeningtheAccessCovers
RemovingtheFrontAccessCover
1.Raisetheloaderarmsandinstallthecylinderlocks.
Note:Inthecasethatyouneedtoremovethefront
accesscoverwithoutraisingtheloaderarms,bevery
carefulnottodamagethecoverorhydraulichoses
asyoumaneuverthecoveroutfromunderthearms.
2.Stoptheengineandremovethekey.
3.Releasethetwolockingtabs(
Figure24,top,lefttab
illustrated).
Figure24
4.Pullthecoveroffofthetractionunit.
5.Whennished,replacethefrontaccesscoverand
secureitwiththetwolockingtabs.
OpeningtheRearAccessCover
1.Stoptheengineandremovethekey.
2.Releasethetwolockingtabsontopoftherearaccess
cover(
Figure25).
Figure25
1.Rearaccesscover
3.Bolt(lanyardnotshown)
2.Lockingtabs
3.Removetheboltlocatednexttotherightlocking
tab(Figure25).
4.Graspingthehandle,pullthecoverupandbackto
swingitopen(
Figure25).
5.Whennished,closetherearaccesscoverby
swingingitupandseatingitinplace.
6.Secureitwiththetwolockingtabsandbolt.
27
