Toro 22337CP - Using Attachments; Installing an Attachment

Figure20
1.Hydraulichoses3.Hairpincotter
2.Cylinderlocks4.Clevispin
UsingAttachments
InstallinganAttachment
Important:UseonlyToro-approvedattachments.
Attachmentscanchangethestabilityandthe
operatingcharacteristicsofthetractionunit.The
warrantyofthetractionunitmaybevoidedifused
withunapprovedattachments.
Important:Beforeinstallingtheattachment,
ensurethatthemountplatesarefreeofanydirtor
debrisandthatthepinsrotatefreely.Ifthepinsdo
notrotatefreely,greasethem.
1.Positiontheattachmentonalevelsurfacewith
enoughspacebehindittoaccommodatethe
tractionunit.
2.Starttheengine.
3.Tilttheattachmentmountplateforward.
4.Positionmountplateintotheupperlipofthe
attachmentreceiverplate(
Figure21).
Figure21
1.Mountplate2.Receiverplate
5.Raisetheloaderarmswhiletiltingbackthemount
plateatthesametime.
Important:Theattachmentshouldberaised
enoughtocleartheground,andthemount
plateshouldbetiltedallthewayback.
6.Stoptheengine.
7.Engagethequickattachpins,ensuringthattheyare
fullyseatedinthemountplate(
Figure22).
Important:Ifthepinsdonotrotatetothe
engagedposition,themountplateisnot
fullyalignedwiththeholesintheattachment
receiverplate.Checkthereceiverplateand
cleanitifnecessary.
Figure22
1.Quickattachpins(shown
inengagedposition)
3.Engagedposition
2.Disengagedposition
WARNING
Ifyoudonotfullyseatthequickattachpins
throughtheattachmentmountplate,the
attachmentcouldfalloffofthetractionunit,
crushingyouorbystanders.
Ensurethatyourquickattachpinsarefully
seatedintheattachmentmountplate.
23
