Note:Thefartheryoumovethetractioncontrol
leversineitherdirection,thefasterthetractionunit
willmoveinthatdirection.
•Tosloworstop,movethetractioncontrollevers
toneutral.
AttachmentTiltLever
•Totilttheattachmentforward,slowlypushthe
attachmenttiltleverforward.
•Totilttheattachmentrearward,slowlypullthe
attachmenttiltleverrearward.
LoaderArmLever
•Tolowertheloaderarms,slowlypushtheloader
armleverforward.
•Toraisetheloaderarms,slowlypulltheloaderarm
leverrearward.
LoaderValveLock
Theloadervalvelocksecurestheloaderarmand
attachmenttiltleverssothatyoucannotpushthem
forward.Thishelpstoensurethatnoonewill
accidentallylowertheloaderarmsduringmaintenance.
Securetheloaderarmswiththelockanytimeyouneed
tostopthemachinewiththeloaderarmsraised.
Tosetthelock,pullitbackandallthewaydownagainst
thelevers(Fig.13).
Note:Youwillneedtomovetheleversrearwardto
engageordisengagetheloadervalvelock.
Figure8
1.Loadervalvelock,
engaged
2.Loadervalvelock,
disengaged
AuxiliaryHydraulicsLever
•Tooperateahydraulicattachmentinforward
direction,slowlypulltheauxiliaryhydraulicslever
upwardandthenrearward.
•Tooperateahydraulicattachmentinreverse
direction,slowlypulltheauxiliaryhydraulicslever
upwardandthenpushitforward.Thisisalsocalled
thedetentpositionbecauseitdoesnotrequire
operatorpresence.
SpeedSelectorLever
WARNING
Ifyoumovethespeedselectorleverwhilethe
tractionunitisinmotion,thetractionunitwill
eitherstopsuddenlyoracceleratequickly.Ifyou
operatethetractionunitwiththespeedselector
leverinanintermediateposition,thetractionunit
willoperateerraticallyandmaybedamaged.You
couldlosecontrolofthetractionunitandinjure
bystandersoryourself.
•Donotmovethespeedselectorleverwhenthe
tractionunitisinmotion.
•Donotoperatethetractionunitwhenthespeed
selectorisinanyintermediateposition(i.e.,
anypositionotherthanfullyforwardorfully
rearward).
•Movethespeedselectorlevertotheforwardposition
tosetthetractiondrive,loaderarms,andattachment
tilttohighspeedandtheauxiliaryhydraulicstolow
speed.
•Movethespeedselectorlevertotherearward
positiontosettheauxiliaryhydraulicstohighspeed
andthetractiondrive,loaderarms,andattachment
tilttolowspeed.
HourMeter
Thehourmeterdisplaysthenumberofhoursof
operationthathavebeenloggedonthetractionunit.
After50hoursandevery75hoursthereafter(thatisat
50,125,200,etc.)thehourmeterdisplaysSVConthe
lowerleftsideofthescreentoremindyoutochangethe
oilandperformtherequiredmaintenance.Afterevery
400hours(400,800,1200,etc.),thehourmeterdisplays
SVConthelowerrightsideofthescreentoremind
youtoperformthemaintenanceproceduresbasedona
400hourschedule.Thesereminderscomeonstarting
threehourspriortotheserviceintervaltimeandashat
regularintervalsforsixhours.
