Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
AdjusttheROPS
2
Nopartsrequired
–
Checkthetirepressure.
3
Nopartsrequired
–
Checkthehydraulicuid,engineoil,
andcoolantlevels.
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Readbeforeoperatingthemachine
EngineOperator'sManual
1
Readbeforeoperatingthemachine
PartsCatalog
1
Usereferencepartnumbers
OperatorTrainingMaterial
1
Viewthevideobeforeoperatingthemachine
1
AdjustingtheROPS
NoPartsRequired
Procedure
1.Removethehairpincotterpinsandthepinsfromthe
rollbar(Figure3).
2.Raisetherollbartotheuprightpositionandinstall
thetwopinsandsecurethemwiththehairpincotter
pins(Figure3).
Note:Ifyoumustlowertherollbar,pushthebar
forwardtorelievepressureonthepins,removethe
pins,lowerthebarslowly,andsecureitwiththepinsso
thatitdoesnotdamagethehood.
Figure3
1.Rollbar3.Hairpincotterpin
2.Pin
