WARNING
Batteryterminalsormetaltoolscouldshortagainst
metalmachinecomponentscausingsparks.Sparks
cancausethebatterygassestoexplode,resulting
inpersonalinjury.
•Whenremovingorinstallingthebattery,donot
allowthebatteryterminalstotouchanymetal
partsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
WARNING
Incorrectbatterycableroutingcoulddamagethe
machineandcablescausingsparks.Sparkscan
causethebatterygassestoexplode,resultingin
personalinjury.
•Alwaysdisconnectthenegative(black)battery
cablebeforedisconnectingthepositive(red)
cable.
•Alwaysconnectthepositive(red)batterycable
beforeconnectingthenegative(black)cable.
StoringtheBattery
Ifthemachinewillbestoredmorethan30days,removethe
batteryandchargeitfully.Eitherstoreitonashelforon
themachine.Leavethecablesdisconnectedifitisstoredon
themachine.Storethebatteryinacoolatmospheretoavoid
quickdeteriorationofthechargeinthebattery.Toprevent
thebatteryfromfreezing,makesureitisfullycharged.The
specicgravityofafullychargedbatteryis1.265-1.299.
DriveSystem
Maintenance
CheckingtheTirePressure
ServiceInterval:Every50hours
Checkthepressureafterevery50operatinghoursormonthly,
whicheveroccursrst.
Maintaintheairpressureinthefrontandreartires.The
correctairpressureis25psi(172kPa)inthereartiresand15
psi(103kPa)inthefronttires.Ifacabisinstalledonthe
machine,thefrontandreartiresshouldbeinatedto25
psi(172kPa).Uneventirepressurecancauseunevencut.
Checkthetireswhentheyarecoldtogetthemostaccurate
pressurereading.
CorrectingSteering
Misalignment
FourWheelDriveModels
1.Pressthesteeringselectorswitchtotherearward(four
wheelssteer)position(Figure52).
Figure52
1.Steeringselectorswitch
TwoandFourWheelDriveModels
2.Onapavedordirtsurface,turnthesteeringwheelto
theleftorrightandcontinueturninguntilall4wheels
havestoppedturning.Automaticsynchronizationof
wheelalignmentshouldoccur.
Important:Doingthisprocedureonturfcan
resultinturfdamagedirectlyundereachofthe
turningtires.
47
