Lubrication

GreasingtheBearingsand

Bushings

ServiceInterval:Every50hours

Themachinehasgreasettingsthatmustbelubricated

regularlywithNo.2GeneralPurposeLithiumBaseGrease.

Ifthemachineisoperatedundernormalconditions,lubricate

allbearingsandbushingsafterevery50hoursofoperation.

Bearingsandbushingsmustbelubricateddailywhen

operatingconditionsareextremelydustyanddirty.Dusty

anddirtyoperatingconditionscouldcausedirttogetinto

thebearingsandbushings,resultinginacceleratedwear.

Lubricatethegreasettingsimmediatelyaftereverywashing,

regardlessofintervalspecied.

1.Wipethegreasettingscleansoforeignmattercannot

beforcedintothebearingorbushing.

2.Pumpgreaseintothettings.

3.Wipeoffexcessgrease.

Figure39
