CheckingthePlanetaryGearDrive
Oil
ServiceInterval:Every400hours
Checktheoillevelafterevery400hoursofoperation
orifexternalleakageisnoted.UsehighqualitySAE
85W-140gearlubeasareplacement.
1.Withmachineonlevelsurface,positionthe
wheelsoonecheckplug(Figure15)isatthe
12o'clockpositionandtheotherisat3o'clock
position.
g019500
Figure15
1.Check/drainplug(2)
2.Removetheplugatthe3o’clockposition(Figure
15).Oillevelshouldbeatthebottomofthe
checkplughole.
3.Iftheoillevelislow,removetheplugatthe12
o’clockpositionandaddoiluntilitbeginstoow
outoftheholeatthe3o’clockposition.
4.Re-installbothplugs.
CheckingtheRearAxleLubricant
ServiceInterval:Every400hours
TherearaxleislledwithSAE85W-140gearlube.
Checktheoillevelbeforetheengineisrststarted
andevery400hoursthereafter.Thecapacityis2.4
liters(80oz).Visuallyinspectforleaksdaily.
1.Positionthemachineonalevelsurface.
2.Removeacheckplugfromoneendoftheaxle
(Figure16)andmakesurethatthelubricantis
uptothebottomofthehole.Ifthelevelislow,
removethellplug(Figure16)andaddenough
lubricanttobringtheleveluptothebottomof
thecheckplugholes.
g011487
Figure16
1.Checkplug
2.Fillplug
CheckingtheRearAxleGearBox
Lubricant
ServiceInterval:Every400hours
ThegearboxislledwithSAE85W-140gearlube.
Checktheoillevelbeforetheengineisrststarted
andevery400hoursthereafter.Thecapacityis0.5
liter(16oz).Visuallyinspectforleaksdaily.
1.Positionthemachineonalevelsurface.
2.Removethecheck/llplugfromtheleftsideof
thegearbox(Figure17)andmakesurethat
lubricantisuptothebottomofthehole.Ifthe
levelislow,addenoughlubricanttobringthe
leveluptothebottomofthehole.
g011488
Figure17
1.Gearbox2.Check/llplug
