Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Handlebolts2
Curvedwashers
2
1
Locknuts2
Installtheupperhandle.
Hairpincotter2
2
Flatwasher3
Installthetractioncontrollinkage.
Nut2
Carriagebolt
2
3
Flatwasher2
Installthechute.
Carriagebolts
2
4
Locknuts2
Installthechutecontrolrod.
5
Nopartsrequired
–
Checktheengineoillevel.
6
Nopartsrequired
–
Checkthetirepressure.
7
Nopartsrequired
–
Checktheskidsandscraper.
8
Nopartsrequired
–
Checktheoperationofthetractiondrive.
1
InstallingtheUpperHandle
Partsneededforthisprocedure:
2Handlebolts
2
Curvedwashers
2Locknuts
Procedure
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).
2.Install2handlebolts,2curvedwashers,and2locknuts
inthelowerhandleholes(Figure3).
g019003
Figure3
