CheckingtheOperationofthe
TractionDrive
NoPartsRequired
Procedure
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine(page12).
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector(page15).
3.Squeezetheleft(traction)levertothehandgrip(Figure
13).
Figure13
Themachineshouldmoverearward.Ifthemachine
doesnotmoveormovesforward,completethe
following:
A.Releasethetractionleverandshutofftheengine.
B.Disconnectthetrunnionfromthespeed-selector
lever(Figure6).
C.Turnthetrunniondownward(clockwise)onthe
speed-controlrod(Figure6).
D.Connectthetrunniontothespeed-selectorlever
(Figure6).
4.Releasethetractionlever.
5.MovethespeedselectortoPosition1;referto
OperatingtheSpeedSelector(page15).
6.Squeezetheleft(traction)levertothehandgrip(Figure
13).
Themachineshouldmoveforward.Ifthemachine
doesnotmoveormovesrearward,completethe
following:
A.Releasethetractionleverandshutofftheengine.
B.Disconnectthetrunnionfromthespeed-selector
lever(Figure6).
C.Turnthetrunnionupward(counterclockwise)on
thespeed-controlrod(Figure6).
D.Connectthetrunniontothespeed-selectorlever
(Figure6).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable;
refertoCheckingandAdjustingtheTractionCable
(page20)ortakethemachinetoanAuthorizedService
Dealerforservice.
