Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Handlebolt2
Curvedwasher
2
1
Locknut2
Installtheupperhandle.
Hairpincotter2
2
Flatwasher3
Installthetraction-controllinkage.
Nut2
Carriagebolt
2
3
Flatwasher2
Installthechute.
Carriagebolt
2
4
Locknut2
Installthechute-controlrod.
5
Nopartsrequired
–
Checktheengine-oillevel.
6
Nopartsrequired
–
Checkthetirepressure.
7
Nopartsrequired
–
Checktheskidsandscraper.
8
Nopartsrequired
–
Checktheoperationofthetractiondrive.
1
InstallingtheUpperHandle
Partsneededforthisprocedure:
2Handlebolt
2
Curvedwasher
2Locknut
Procedure
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure4).
2.Install2handlebolts,2curvedwashers,and2locknuts
inthelowerhandleholes(Figure4).
g019003
Figure4
