Toro 38622 - Setup and Assembly

1
2
3
4
5
6
5
7
Tecumseh Part No. 35077
1. Key ignition
5. Increasing scale
2. Engage to start the engine 6. Slow
3. Disengage to stop the engine 7. Stop the engine
4. Fast
Tecumseh Part No. 37119
106-4521
Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Step
Description
Qty.
Use
Handle bolts
4
Curved washers
4
1.
Locknuts
4
Install the upper handle.
2.
No parts required
–
Install the traction control linkage.
Carriage bolts
2
3.
Locknuts
2
Install the chute control rod.
4.
Cable ties
2
Connect the wire to the headlight.
5.
No parts required
–
Fill the engine with oil.
6.
No parts required
–
Check the tire pressure.
7.
No parts required
–
Check the skids and scraper.
5
