Toro 38657C User Manual

9.CheckingtheTractionDrive
Operation
Procedure
Ifthetractiondriveisnotproperlyadjusted,
thesnowthrowermaymoveinthedirection
oppositeofwhatyouintended,causinginjury
and/orpropertydamage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine.
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.
3.Squeezethelefthand(traction)levertothehand-grip
(Figure19).
Figure19
Thesnowthrowershouldmoverearward.Ifthe
snowthrowerdoesnotmoveormovesforward,
completethefollowing:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
4.Releasethetractionlever.
5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(Figure19).
Thesnowthrowershouldmoveforward.Ifthe
snowthrowerdoesnotmoveormovesrearward,
completethefollowing:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunnionupward(counterclockwise)on
thespeedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthesnowthrowermoveswhenthe
tractionleverisinthereleasedposition,checkthe
tractioncable(refertoCheckingandAdjusting
theTractionCable)ortakethesnowthrowertoan
AuthorizedServiceDealerforservice.
ProductOverview
Figure20
1.Hand-grip(2)
9.Dischargechute
2.Auger/impellerlever10.Scraper
3.Speedselectorlever
11.Auger
4.QuickStick™discharge
chutecontrol
12.Skid(2)
5.Tractionlever13.Electricstarterbutton
6.Fueltankcap
14.Snowcleanouttool
7.Engineoillltube/dipstick
15.Headlight
8.Chutedeector16.Wheelclutchlever(2)
11
