ChuteGearRemoval(continued)
g324235
Figure38
15.Removethe2screwssecuringthegearbrackettotherearchuteandthe
housing.
g320270
Figure39
16.Removethegearbracketandattachedsectorgearfromthechutegear.
17.Removethechutegearfromtherearchute.
ChuteGearInstallation
1.Installthechutegearontherearchutesothatthechutegeararrowisaligned
betweenthetwoverticallinesonthechute.
