ChuteGearInstallation(continued)
g321111
Figure40
2.Clockthesectorgeartothechutegearbyaligningthemiddledotofthe
sectorgearbetweenthetwodoesofthechutegear.
g321112
Figure41
3.Installthe2screwssecuringthegearbrackettotherearchuteandhousing.
Torquethescrewsto1.1-1.7N•m(10-15in-lb).
60VMAXe21PowerClear®SnowThrowerwith
Flex—ForcePowerSystem®ServiceManual
Page6–9
Chute:ServiceandRepairs
3438-775RevA
