DashPanelAssemblyRemoval(continued)
g320295
Figure60
10.Separatethefrontandreardashpanelsfromtheupperhandleassembly.
DashPanelAssemblyInstallation
1.Positionthefrontandreardashpanelsontotheupperhandleassembly.
2.Installthe4nutsand4handlescrewssecuringthefrontandreardashpanels
ontotheupperhandle.T orquetheangenutsto4.5–5.6N•m(40–50in-lb).
g320295
Figure61
3.Install5screwssecuringthefrontandreardashpanels.Torquethescrews
to1.1-1.7N•m(10-15in-lb)
