11.Movethemotion-controlleverstotheREVERSE
positionandwhileapplyingslightpressureto
thelever,allowthereverse-indicatorspringsto
bringtheleversbacktoneutral.
Note:Thewheelsshouldstopturningorslightly
creepinreverse.
12.Shutoffthemachine.
13.Removethejumperwirefromthewireharness
andplugtheconnectorintotheseatswitch.
14.Removethejackstands.
15.Raisethemowerdeckandinstallthe
height-of-cutpin.
16.Checkandensurethatthemachinedoes
notcreepinneutralwiththeparkingbrake
disengaged.
Adjustingthe
Motion-ControlDamper
Youcanadjustthetopdamper-mountingbolttoobtain
thedesiredmotion-controlleverresistance.Referto
Figure93formountingoptions.
g008620
Figure93
RightMotionControlShown
1.Torquethelocknutto23N∙m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
Adjustingthe
Motion-Control
Neutral-LockPivot
Youcanadjusttheangednuttoobtainthedesired
motion-controlleverresistancewhenmovingittothe
NEUTRAL-LOCKposition.SeeFigure94foradjustment
options.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesired
feel.
•Formoreresistance,tightentheangednut.
•Forlessresistance,loosentheangednut
3.Tightenthejamnut.
g008621
Figure94
1.Flangednut2.Jamnut
63
