ProductOverview
g027333
Figure4
1.Deck-liftpedal
6.Rollbar
2.Transportlock
7.Seatbelt
3.Parking-brakelever8.Fuelcap
4.Controls
9.Mowerdeck
5.Motion-controllevers
10.Casterwheel
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g013112
Figure5
1.Blade-controlswitch
(powertakeoff)
4.Hourmeter
2.Throttlecontrol
5.Keyswitch
3.Malfunction-indicatorlight
(MIL)
6.Fuses
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page25).
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure5).
ChokeControl
Usethechokecontroltostartacoldengine.
13
