Toro 74389 - Adjusting the Height-Of-Cut; Positioning the Seat; Adjusting the Motion-Control Levers

AdjustingtheHeight-of-Cut
Height-of-cutiscontrolledbytheleverlocatedtotherightof
theoperatingposition(Figure21).
G015319
1
2
3
Figure21
1.Height-of-cutlever3.115mm(4.5
inches)—transport
position
2.Height-of-cutpositions
1.Pullupandinwardonthelevertomoveittothe
desiredcuttingposition.
2.Onceatthedesiredcuttingposition,slowlylowerthe
leveruntilitengagestheposition.
Note:Thetransportpositionisthehighestheight-of-cut
positionorcuttingheight(115mm(4.5inches))asshown
inFigure21.
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
1.Raisetheseatandloosentheadjustmentboltsjust
enoughthatseatcanmove(
Figure22).
G014477
1
Figure22
1.Adjustmentbolt
2.Movetheseattothedesiredpositionandtightenthe
bolts.
AdjustingtheMotion-control
Levers
AdjustingtheHeight
Themotion-controlleverscanbeadjustedhigherorlowerfor
maximumoperatorcomfort.
1.Removethe2boltsholdingthecontrollevertothe
control-armshaft(Figure23).
2.Movethecontrollevertothenextsetofholes.
3.Securetheleverwiththe2bolts(Figure23).
4
1
2
G014970
3
Figure23
1.Control-armshaft3.Slotted,upperhole
2.Controllever
4.Bolt
21
