Toro 74785 - Raising the Seat; Raising the Front of the Machine; Lubrication; Greasing the Bearings

RaisingtheSeat
Ensurethattheparkingbrakeisengagedandliftthe
seatforward.
Youcanaccessthefollowingcomponentsbyraising
theseat:
•Serialplate
•Servicedecal
•Seat-adjustmentbolts
•Fuellter
•Batteryandbatterycables
RaisingtheFrontofthe
Machine
Ifthefrontofthemachineneedstoberaised,usethe
veryfrontedgeasshowninFigure25.
Important:Topreventdamagetothesteering
mechanism,usetheveryfrontedgeofthe
machineforajackingpoint.
g028320
Figure25
Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greaseallthe
lubricationpoints.
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurface,and
disengagetheblade-controlswitch.
2.Ensurethattheparkingbrakeisengaged,shut
offtheengine,removethekeyfromthekey
switch,andwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
3.Cleanthegreasettings(Figure26andFigure
27)witharag.
Note:Makesuretoscrapeanypaintoffthe
frontofthetting(s).
g027752
Figure26
1.Frontcastertire
decal106-8717
Figure27
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance
3.Greaseevery25operating
hours
2.Checkthetirepressure
every25operatinghours
4.Engine
4.Connectagreaseguntoeachtting(Figure26
andFigure27).
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings.
27
