G015033
1
2
3
Figure9
1.SafeZone-usethemachinehere
2.Usewalkbehindmowerand/orhandtrimmerneardrop-offs
andwater.
3.Water
UsingtheRolloverProtection
System(ROPS)
WARNING
Toavoidinjuryordeathfromrollover:keepthe
rollbarinthefullyraisedlockedpositionanduse
theseatbelt.
WARNING
Thereisnorolloverprotectionwhentherollbar
isinthedownposition.
•Lowertherollbaronlywhenabsolutely
necessary.
•Donotweartheseatbeltwhentherollbaris
inthedownposition.
•Driveslowlyandcarefully.
•Raisetherollbarassoonasclearancepermits.
•Checkcarefullyforoverheadclearances(i.e.
branches,doorways,electricalwires)before
drivingunderanyobjectsanddonotcontact
them.
Important:Lowertherollbaronlywhen
absolutelynecessary.
1.Toraisetherollbar,removethehaircotterpinand
removethelockingpins.
2.Raisetherollbartotheuprightposition(Figure10).
G015034
Figure10
Important:Alwaysusetheseatbeltwiththe
rollbarinthefullyraisedposition.
3.Installthelockingpins.Securethepinsbyinstalling
thehaircotterpin(Figure11).
G015035
1
2
3
2
Figure11
1.HoleinROPS
3.Hairpincotter
2.Lockingpin
4.Twolowertherollbar,removethehaircotterpin
andremovethelockingpin.(Figure11).
5.Lowertherollbartothedownposition.
6.Usethetwolockingandcotterpinstosecurethe
bar.
