Toro 74841 - Operating the Throttle; Operating the Choke; Operating the Ignition Switch

ReleasingtheParkingBrake
G010079
1
2
Figure15
OperatingtheThrottle
ThethrottlecontrolcanbemovedbetweenFastand
Slowpositions(Figure16).
Alwaysusethefastpositionwhenturningonthe
mowerdeckwiththebladecontrolswitch(PTO).
G008946
Figure16
OperatingtheChoke
Usethechoketostartacoldengine.
1.Iftheengineiscold,usethechoketostartthe
engine.
2.Pulluponthechokeknobtoengagethechoke
beforeusingtheignitionswitch(
Figure17).
3.Pushdownonthechoketodisengagethechoke
aftertheenginehasstarted(
Figure17).
G008959
1
2
Figure17
1.On2.Off
OperatingtheIgnitionSwitch
1.TurntheignitionkeytotheStartposition
(Figure18).Whentheenginesstarts,releasethekey.
Important:Donotengagestarterformore
than5secondsatatime.Iftheenginefails
tostartallowa15secondcool-downperiod
betweenattempts.Failuretofollowthese
instructionscanburnoutthestartermotor.
Note:Additionalstartingcyclesmayberequired
whenstartingtheengineforthersttimeafterthe
fuelsystemhasbeenwithoutfuelcompletely.
START
RUN
ST OP
G008947
Figure18
2.Turntheignitionkeytostoptostoptheengine.
