PositioningtheSeat
Theseatcanmoveforwardandbackward.Positionthe
seatwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
Whilesittingintheoperator'sposition,raisetheseat
adjustmentleverslightlyandmovetheseatforwardor
backwardtothedesiredposition(Figure30).
G010232
1
Figure30
1.Adjustmentlever
AdjustingtheMotionControl
Levers
AdjustingtheHeight
Themotioncontrolleverscanbeadjustedhigheror
lowerformaximumoperatorcomfort.
1.Removethe2boltsand2washersholdingthe
controllevertothecontrolarmshaft(Figure31).
2.Movethecontrollevertothenextsetofholes.
Securetheleverwiththe2boltsand2washers
(
Figure31).
4
1
2
G014970
3
Figure31
1.Controlarmshaft
4.Washer
2.Controllever
5.Bolt
3.Slotted,upperhole
3.Repeattheadjustmentfortheoppositecontrol
lever.
