Toro 74919TE - Adjusting the Tracking; Checking the Tire Pressure

Figure65
1.ROPSknob(locked
position)
3.Rollbarintheupright
position
2.PulltheROPSknobout,
androtateit90degrees
tochangetherollbar
position.
4.Rollbarinthefolded
position
AdjustingtheTracking
1.Disengagetheblade-controlswitch(PTO).
2.Drivetoanopen,atareaandmovethemotion-control
leverstotheNEUTRAL-LOCKposition.
3.MovethethrottlemidwaybetweentheFASTandSLOW
positions.
4.Movebothmotion-controlleversforwarduntilthey
bothhitthestopsintheT-slot.
5.Checkwhichwaythemachinetracks.
6.Ifthemachinetrackstotheright,loosentheboltsand
adjusttheleftstopplaterearwardontheleftT-slot
untilthemachinetracksstraight(Figure66).
7.Ifthemachinetrackstotheleft,loosentheboltsand
adjusttherightstopplaterearwardontherightT-slot
untilthemachinetracksstraight(Figure66).
8.Tightenthestopplate(Figure66).
g027340
Figure66
Leftcontrollevershown
1.Controllever3.Stopplate
2.Bolt
CheckingtheTirePressure
ServiceInterval:Every50hours/Monthly(whichever
comesrst)
Maintaintheairpressureinthereartiresat90kPa(13psi).
Uneventirepressurecancauseunevencut.Checkthetires
whentheyarecoldtogetthemostaccuratepressurereading.
Note:Thefronttiresaresemi-pneumatictiresanddonot
requireairpressuremaintenance.
Figure67
46
